Elevate your scanning experience with the Z-3102, the enhanced edition of ZEBEX's middle-range handheld 2D image scanner series. This device introduces cutting-edge features meticulously engineered to transform your scanning process and propel your efficiency to extraordinary levels. Powered by advanced image processing technology, the Z-3102 excels in reading 1D, 2D, and postal barcodes at high speed from any direction and offers an ergonomic design for user comfort and boasts low power consumption.

Streamline design and large trigger for effortless operation
Captures barcodes on mobile phones, tablets, or computer screens
High speed, omnidirectional reading of 1D, 2D and postal barcodes
Extremely low power consumption
Affordable high performance

Aiming Element
617 nm LED

Illumination Element
White LED

Optical System
1280H × 800V CMOS

Depth of Field
Code39 ( 4 mil ) : 30 - 130 mm Code39 ( 5 mil ) : 30 - 160 mm EAN 13 ( 13 mil ) : 30 - 300 mm QR Code ( 7 mil ): 30 - 125 mm Data Matrix ( 7 mil ): 40 - 130 mm

Min. Bar Width
4 mils (Code39)

Print Contrast
30% @ UPC/EAN 100%

Indicator
Blue LED

Beeper Operation
Programmable ton & beep time

System Interface
RS-232 & USB

Dimensions (H x W x L)
152.3 x 64.4 x 104.9 mm

Weight
86.5g
